| Technical Specifications |
|
|
|
| Thrust Washer: |
According to ASTM D3702 |
| Pin on Disc: |
According to ASTM G99 |
| Pin Track Radius: |
10 to 35 mm |
| Pin Size: |
8 mm diameter x 15 mm long |
| Disc Diameter: |
75 mm maximum |
| Load Range: |
20 to 750 N (@ 6 bar air pressure) |
| Loading Method: |
Pneumatic |
| Load Measurement: |
Pressure transducer |
| Load Control: |
Precision pressure regulator |
| Friction Measurement: |
Databeam strain gauge transducer |
| Torque Reaction Mounting: |
Air bearing |
| Temperature Range: |
Ambient to 200°C |
| Heater Power: |
550 W |
| Temperature Sensor: |
k-type thermocouple |
| Rotational Speed: |
30 to 1,800 rpm |
| Motor: |
1.5 kW a.c. vector motor |
| Control & Data Acquisition: |
Touch-screen PC & Interface |
| Data Export: |
USB Stick |
|
|
| Automatically Controlled Parameters |
Rotational Speed |
|
Temperature |
|
Test Duration |
|
|
| Manually Controlled Parameters |
Load |
|
|
| Measured Parameters |
Rotational Speed |
|
Wear (Optional) |
|
Friction Force |
|
Temperature |
|
Number of Revolutions |
|
Test Duration |
|
Sliding Speed |
|
Friction Coefficient |
|
Sliding Distance |
|
|
| Services |
|
| Electricity: |
220/240V, single phase, 50 Hz, 3.0 kW |
|
110/120 V, single phase, 60 Hz, 3.0 kW |
| Clean, dry air: |
4 cfm at 8 bar (120 psi) |
